Square speaker

Overview of the advantages of Loudspeakers:

  • Widest frequency range and best sound, compared with other sound solutions
  • Different Impedances available
  • Differend diameter and frequencies available
  • Wire/connector assembly available on request
  • Automotive specification and sound solution available on request

There are 10 of 45 products shown.

25KE08

  • Length [mm]: 25 mm
  • Width [mm]: 25 mm
  • Height [mm]: 8.8 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 2,000 mW
  • SPL [dB]: 80 dB
  • Frequency [Hz]: 200 Hz ... 20,000 Hz
  • Manufacturer: Veco
25KE08

25KP08

  • Length [mm]: 27 mm
  • Width [mm]: 14 mm
  • Height [mm]: 7.2 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 2,000 mW
  • SPL [dB]: 80 dB
  • Frequency [Hz]: 400 Hz ... 20,000 Hz
  • Manufacturer: Veco
25KP08

27CS08FK-6

  • Length [mm]: 27 mm
  • Width [mm]: 23 mm
  • Height [mm]: 3.7 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 500 mW
  • SPL [dB]: 78 dB
  • Frequency [Hz]: 400 Hz ... 20,000 Hz
  • Manufacturer: Veco
27CS08FK-6

28KUG04X-W

  • Length [mm]: 28 mm
  • Width [mm]: 28 mm
  • Height [mm]: 11.2 mm
  • Impedance [Ω]: 4 Ω
  • Normal Power [mW]: 2,000 mW
  • SPL [dB]: 80 dB
  • Frequency [Hz]: 180 Hz ... 18,000 Hz
  • Manufacturer: Veco
28KUG04X-W

40KC08-3

  • Length [mm]: 40 mm
  • Width [mm]: 14 mm
  • Height [mm]: 11.3 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 3,000 mW
  • SPL [dB]: 82 dB
  • Frequency [Hz]: 200 Hz ... 20,000 Hz
  • Manufacturer: Veco
40KC08-3

32KUG08XNT-W

  • Length [mm]: 32.7 mm
  • Width [mm]: 32.7 mm
  • Height [mm]: 16.5 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 3,000 mW
  • SPL [dB]: 85 dB
  • Frequency [Hz]: 200 Hz ... 20,000 Hz
  • Manufacturer: Veco
32KUG08XNT-W

3516KMG04HX

  • Length [mm]: 35 mm
  • Width [mm]: 16 mm
  • Height [mm]: 7.8 mm
  • Impedance [Ω]: 4 Ω
  • Normal Power [mW]: 2,000 mW
  • SPL [dB]: 83 dB
  • Frequency [Hz]: 380 Hz ... 20,000 Hz
  • Manufacturer: Veco
3516KMG04HX

35KM08

  • Length [mm]: 35 mm
  • Width [mm]: 16 mm
  • Height [mm]: 5 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 1,000 mW
  • SPL [dB]: 81 dB
  • Frequency [Hz]: 400 Hz ... 20,000 Hz
  • Manufacturer: Veco
35KM08

35KP08

  • Length [mm]: 35 mm
  • Width [mm]: 16 mm
  • Height [mm]: 8 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 1,000 mW
  • SPL [dB]: 84 dB
  • Frequency [Hz]: 380 Hz ... 13,000 Hz
  • Manufacturer: Veco
35KP08

35KS08

  • Length [mm]: 35 mm
  • Width [mm]: 20 mm
  • Height [mm]: 8 mm
  • Impedance [Ω]: 8 Ω
  • Normal Power [mW]: 1,000 mW
  • SPL [dB]: 86 dB
  • Frequency [Hz]: 300 Hz ... 11,000 Hz
  • Manufacturer: Veco
35KS08
