Nisshinbo

Nisshinbo Micro Devices Inc. Your Partner for Analog Solution

NISSHINBO was founded at the beginning of 2022 through the merger of NJR and RICOH and has over 60 years of experience in alalog semiconductor. The company is focused on development and production of high quality OPAmps, Power Management IC, audio and RF device. Using bipolar, CMOS and BCD technology Nisshinbo provides a wide range of products for consumer as well for industrial and automotive application.
Using own factories and technology they can commit for long term supply and also customer made device with high quality standards.


Productportfolio

Operational Amplifier, Comparator, Switching Regulator, LDO, AD- and DA Converterr, Supervision IC, RF-switch, LNA, Radar-Modue, Photodiode and ASIC

Possible Application

  • Healtcare
  • Wireless Communication
  • Automotive
  • Consumer
  • Industrial

Certifications and quality management

  • ISO 9001:2015
  • ISO 14001:2015
  • IATF 16949:2016

There are 10 of 800 products shown.

RP154-Y

  • Package (Linearregler LDO): DFN1216-8, DFN2020-8, SOT-23-6
  • Vin [V]: 1.4 V ... 5.25 V
  • Vout [V]: 0.8 V ... 3.7 V
  • Iout [mA]: 300 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.2 μA
  • Manufacturer: Nisshinbo
RP154-Y

RP155

  • Package (Linearregler LDO): WLCSP-5-P1
  • Vin [V]: 1.9 V ... 5.25 V
  • Vout [V]: 1.6 V ... 3.6 V
  • Iout [mA]: 200 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP155

RP170

  • Package (Linearregler LDO): SOT-23-5, SOT-89-5
  • Vin [V]: 2.6 V ... 10 V
  • Vout [V]: 1.2 V ... 6.5 V
  • Iout [mA]: 300 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP170

RP170-Y

  • Package (Linearregler LDO): SOT-23-5, SOT-89-5
  • Vin [V]: 2.6 V ... 10 V
  • Vout [V]: 1.2 V ... 6.5 V
  • Iout [mA]: 300 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP170-Y

RP171

  • Package (Linearregler LDO): SC-88A, SOT-23-5
  • Vin [V]: 2.6 V ... 10 V
  • Vout [V]: 1.2 V ... 6.5 V
  • Iout [mA]: 150 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP171

RP171-Y

  • Package (Linearregler LDO): SC-88A, SOT-23-5
  • Vin [V]: 2.6 V ... 10 V
  • Vout [V]: 1.2 V ... 6.5 V
  • Iout [mA]: 150 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP171-Y

RP173

  • Package (Linearregler LDO): DFN(PL)1010-4, SOT-23-5
  • Vin [V]: 2.5 V ... 11 V
  • Vout [V]: 1.2 V ... 5.5 V
  • Iout [mA]: 150 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.2 μA
  • Manufacturer: Nisshinbo
RP173

RP200

  • Package (Linearregler LDO): DFN(PL)1212-6, SOT-23-5
  • Vin [V]: 1.4 V ... 5.25 V
  • Vout [V]: 0.8 V ... 4 V
  • Iout [mA]: 300 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP200

RP201

  • Package (Linearregler LDO): DFN(PL)1212-6
  • Vin [V]: 1.4 V ... 5.25 V
  • Vout [V]: 0.8 V ... 4 V
  • Iout [mA]: 150 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP201

RP202

  • Package (Linearregler LDO): DFN(PL)1010-4, SC-88A, SOT-23-5
  • Vin [V]: 1.4 V ... 5.25 V
  • Vout [V]: 0.8 V ... 4 V
  • Iout [mA]: 200 mA
  • Accuracy [±%]: 1 ±%
  • Standby Current [µA]: 0.1 μA
  • Manufacturer: Nisshinbo
RP202
