MOS Relays

A MOS Relay, also called PhotoMOS or solid state relay (SSR) with MOSFET output, is a device with a function similar to a mechanical relay, but purely on semiconductor, non mechanical basis.
An infrared-LED is coupled optically via a transparent isolating material to a photo MOS-FET within one housing.
Excel Cells (ECE) MOS Relays are available with the switching behaviour normally open and normally closed.

Features

  • DIL, SMD and Mini-flat (SOP) housing
  • Load current IL = 130 … 400 mA
  • Load voltage VB = 60 … 400 V
  • On-resistance Ron = 0.83 … 28 W
  • Isolation voltage Viso up to 5.000V
  • UL and TÜV approval available
  • REACH & RoHS compliant

downloads

There are 10 of 140 products shown.

EL425A(S)(TU)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 250 V
  • IL [mA]: 150 mA
  • RON typ. [Ω]: 6.5 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL425A(S)(TU)-V

EL425A(S)(TA)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 250 V
  • IL [mA]: 150 mA
  • RON typ. [Ω]: 6.5 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL425A(S)(TA)-V

EL425A(S)(TD)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 250 V
  • IL [mA]: 150 mA
  • RON typ. [Ω]: 6.5 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL425A(S)(TD)-V

EL425A(S)(TB)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 250 V
  • IL [mA]: 150 mA
  • RON typ. [Ω]: 6.5 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL425A(S)(TB)-V

EL440A(S)(TU)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 400 V
  • IL [mA]: 120 mA
  • RON typ. [Ω]: 20 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL440A(S)(TU)-V

EL440A(S)(TA)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 400 V
  • IL [mA]: 120 mA
  • RON typ. [Ω]: 20 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL440A(S)(TA)-V

EL440A(S)(TD)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 400 V
  • IL [mA]: 120 mA
  • RON typ. [Ω]: 20 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL440A(S)(TD)-V

EL440A(S)(TB)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 400 V
  • IL [mA]: 120 mA
  • RON typ. [Ω]: 20 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL440A(S)(TB)-V

EL460A(S)(TU)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 600 V
  • IL [mA]: 50 mA
  • RON typ. [Ω]: 40 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL460A(S)(TU)-V

EL460A(S)(TD)-V

  • Package: SMD-4
  • Type: Normal Open
  • VB [V]: 600 V
  • IL [mA]: 50 mA
  • RON typ. [Ω]: 40 Ω
  • VISO [V]: 5,000 V
  • Manufacturer: Everlight
EL460A(S)(TD)-V
